Phoenix Contact MCR-C-U/U-10V/B Analog Isolating Amplifier – Part No. 2786568 – used

Name: Phoenix Contact MCR-C-U/U-10V/B Analog Isolating Amplifier – Part No. 2786568 – used
Brand: Phoenix Contact
SKU: 2786568
Price: 164.00 EUR
Availability: InStock

€164,00 EUR

excl. VAT Shipping calculated at checkout.

In stock · ships immediately

We pack your order on the day you place it. The carrier collects it on the next working day.

Delivery date for your postcode

Germany: 2–3 working days
EU: 3–5 working days
Worldwide: on request

Secure payment

You choose your payment method at checkout.

No PayPal account? Via the cart you can also pay by credit card or with any of the other methods shown.

Your payment data is processed in encrypted form. We do not store any credit card data.

Phoenix Contact Signal Conditioner Used

Phoenix Contact MCR-C-U/U-10V/B Analog Isolating Amplifier – Item No. 2786568

Analog signal isolator and voltage converter for industrial automation and control – galvanic isolation up to 1.5 kV, tested and fully functional.

2786568

Item No.

±10 V

Input / Output

1.5 kV

Isolation

18–30 V DC

Supply

Tested

Condition

Before you order: please compare type MCR-C-U/U-10V/B and item number 2786568 with your existing module. Send us a photo of your label and we confirm the fit before shipping.

Technical data

Manufacturer	Phoenix Contact
Type	MCR-C-U/U-10V/B
Item number	2786568
Device type	Isolating amplifier / signal converter
Input signal	±10 V
Output signal	±10 V
Input resistance	> 1 MΩ
Output load resistance	> 10 kΩ
Measuring error	0.1 %
Cut-off frequency	30 Hz
Isolation	1.5 kV / 50 Hz / 1 min
Supply voltage	18–30 V DC
Current consumption	approx. 15 mA
Operating temperature	-20 °C to +65 °C
Mounting	DIN rail
Condition	Used · tested, fully functional

Product description

The Phoenix Contact MCR-C-U/U-10V/B, item number 2786568, is a high-quality analog isolating amplifier and signal converter for industrial measurement and control. It provides reliable galvanic isolation and conditioning of analog voltage signals.

The module processes input signals up to ±10 V and delivers a correspondingly conditioned output signal. The built-in galvanic isolation (1.5 kV) effectively prevents interference, potential differences and equalizing currents between different parts of a plant.

Its slim DIN-rail design saves space in control cabinets; pluggable screw terminals make wiring and service replacement quick. This unit comes from industrial use, has been tested and is in used, fully functional condition.

Compatibility & applications

Control cabinetsPLC controlsProcess control systemsCNC machinesPackaging machinesConveyor systemsPhoenix Contact MCR replacementRetrofit

Scope of delivery

1 × Phoenix Contact MCR-C-U/U-10V/B isolating amplifier, Item No. 2786568.
